Description

The ThinkSystem 5400 MAX Mixed Use SATA 6Gb SSDs are advanced data center SSDs optimized for mixed read-write performance and endurance. These self-encrypting SSDs (SEDs) are based on the Micron 5400 MAX platform and are available in capacities ranging from 480GB to 3.84TB. They are engineered for greater performance and endurance in a cost-effective design, and to support a broader set of workloads.

This product guide provides essential presales information to understand the 5400 MAX SSDs, their key features and specifications, components and options, and configuration guidelines. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the 5400 MAX SSDs and consider their use in IT solutions.

Key Features

• Industry standard 2.5-inch form factor
• Compliant with the Trusted Computing Group Enterprise Security Subsystem Class cryptographic standard (TCG Enterprise SSC)
• Supports the SafeStore self-encrypting drive (SED) functionality of ThinkSystem RAID adapters
• New generation 176-layer 3D TLC NAND flash memory
• Suitable for read-intensive workloads with an endurance of up to 5.0 full drive writes per day (DWPD) for 5 years
• 6 Gbps SATA host interface
• High reliability and enhanced ruggedness
• Absence of moving parts to reduce potential failure points in the server
• S.M.A.R.T. support
• Advanced Encrypting Standard (AES) 256-bit encryption
• Supports Sanitize Cryptographic Erase

Gallery

Manufacturer Specifications
